Multi-cartridge Flushing Slot Filter, Self Cleaning

Filters for cleaning from mechanical contamination are steel cylindrical devices with a one-piece or dismountable housing. Inside the housing slotted (mesh) filter screens or cartridges "TEKO-SLOT" are installed. The package also includes the necessary fasteners and counter flanges.

Equipment parameters:

Price - on request

Warranty - 24 months

Delivery - Worldwide


Multi-cartridge Flushing Slot Filter, Self Cleaning

Slotted mesh filters are used for cleaning liquids and gases from solid suspended particles in technological schemes of water treatment, water supply, water disposal and recycling.

Slotted filters (FSCH) are used for removing suspended particles from 0.8 to 3 mm in size

Principles of operation of a mechanical cleaning filter and a self-washing filter (video):

Specifications are shown in the table below:

Description Value
Filtration capacity, m3/h 50-3000
Mesh size, mm 0,05-3
Internal operating pressure, MPa (kg/cm2) up to 6.0 (60)
Operating temperature of filtered material, С from -10 to +150
Material of the vessel and internal components carbon steel
stainless steel
fibre-glass and composite
